Madison M4189 EPDM Tilt Float Switch, 8A Contact Rating, 1 Bar Pressure, 6.5' Cable Length

4.7 / 5

Product ID:

225687

Identifier:

B009092TW4

Brand:

Madison

Model:

M4189

Shipping Weight:

1.3 lbs

Manufacturer:

Madison Company

Shipping Dimension:

9.09 x 5.39 x 2.4 inches

Share on Social Media

Share on Facebook

Share on X

Share on Instagram

Share on Tiktok

₱5,181

+ ₱ 662

International Shipping

Shipping Cost from USA to Philippines inclusive of custom fees.

Cost too high? Check weight and dimension on product details and click "I think this is wrong?" link.

Get it between 2026-06-04 to 2026-06-11.

Additional 3 business days for provincial shipping.

- Price and Stocks may change without prior notice

- Packaging of actual item may differ from photo shown

Electrical items MAY be 110 volts.

See more details
7 Day Return Policy

See more details
Cash On Delivery/Cash Upon Pickup Available

Cash upon Pick-up - orders grand total must not exceed ₱5,000.00. Order will be pickup at Galleon's Office.

Cash on Delivery - orders grand total must not exceed of ₱10,000.00 and must not exceed ₱5,000.00 for provincial areas. See all payment methods

FEATURES

Low cost

Easy installation

Versatile in application

6.5' (2 meters) cable length

Float travel is approximately +/-45 degree are from its nominal position

DESCRIPTIONS

Madison Company's M4189 tilt float switch is an inexpensive, efficient and highly reliable level detector for open vessels, sumps and ponds. Standard cable length is 6.5' (2 meters) of PVC Jacket. The molded rubber float has an integral three conductor cable and operates on a micro-switch device that is located inside the float on an anti vibration mount. The rubber float is constructed of ethylene propylene diene (EPDM), a synthetic rubber with rigid and durable characteristics for long service life and resistance to heat, oxidation, ozone and aging due to weather. As a non-polar elastomer, EPDM has good electrical resistivity, as well as resistance to polar solvents such as water, acids, alkalies, phosphate esters and many ketones and alcohols. The basic operating principle is that as the fluid level rises the float will rise, causing the micro switch to tilt and generate a signal that can be used to start or stop a pump, open or close a valve or actuate indicator alarms as required. Float travel is approximately +/-45 degree are from its nominal position. Low cost, easy installation, versatile in application. Stem and float SG 2.16 g/cubic cm. 65 ft Maximum submerged depth. Directly 1 KW with 250 V circuit breaking capacity. Polypropylene sealed housing. Contact rating: 16 (8) A 250V ~ 16(4)A 380V.
