Carlin 60200FRS Flame Rod Gas Burner Primary Control for EZ-Gas, EZ-Gas Pro & 201GAS Burners. Now with LCD Screen! Replaces Carlin 6020002FRS, 602000FRS, 60200-02FR, 6020002FR, 602002FR363S

4 / 5

Product ID:

124263

Identifier:

B06XQMDT3W

Brand:

Carlin

Model:

Shipping Weight:

1.76 lbs

Manufacturer:

CARLIN

Shipping Dimension:

7.99 x 5.98 x 4.02 inches

Share on Social Media

Share on Facebook

Share on X

Share on Instagram

Share on Tiktok

₱14,147

+ ₱ 543

International Shipping

Shipping Cost from USA to Philippines inclusive of custom fees.

Cost too high? Check weight and dimension on product details and click "I think this is wrong?" link.

Get it between 2025-11-17 to 2025-11-24.

Additional 3 business days for provincial shipping.

- Price and Stocks may change without prior notice

- Packaging of actual item may differ from photo shown

Electrical items MAY be 110 volts.

See more details
7 Day Return Policy

See more details
Cash On Delivery/Cash Upon Pickup Available

Cash upon Pick-up - orders grand total must not exceed ₱5,000.00. Order will be pickup at Galleon's Office.

Cash on Delivery - orders grand total must not exceed of ₱10,000.00 and must not exceed ₱5,000.00 for provincial areas. See all payment methods

FEATURES

***Important Note*** When Installing On A Covered Burner You Must Also Purchase The 33902FS Low Profile Junction Box. It Is NOT Included With This Control.

Replaces Carlin 6020002FRS, 602000FRS, 60200-02FR, 6020002FR, 602002FR363S, 602002FR-363S

Now With LCD Screen!

DESCRIPTIONS

Features: On-Board LCD Screen Easy to Understand Icons for Inputs and Outputs Displays micro-amp Flame reading Display operational information Fault History records last 50 fault cycles to aid the technician in troubleshooting Field Settable Timings Pre-purge (0, 10, 30, 90) Trial for Ignition Time (4, 6) Post-Purge (0, 10, 15, 30, 60, 120) Number of Recycles allowed (0, 1, 3) Serviceman Reset Protection (3) Low Voltage Terminals TT (can be programmed as Used or Not used) Blocked Vent input (contact closure, functions as a low voltage limit) CO input (contact closure) required to start C.F.H ., lockout if not detected during run Alarm output (dry contacts) 24VAC/DC Power input (red/white wire) 120 VAC, 60 HZ, 9 VA Limit circuit input (black wire) 120 VAC, 60 HZ Motor load (orange wire) 10 FLA / 60 LRA (reduce by valve and ignition load) Ignitor load (blue wire) 120 VAC, 60 HZ, 500 VA Valve load (violet wire) 2 amps Aux 120 VAC, 1 amp Alarm contacts (dry contacts) 24V, AC/DC, 2A Operating temperature limits +32°F to +140°F Storage temperature limits -40°F to +185°F Thermostat 24 VAC, 0.1A Blocked Vent 12 VDC. 2mA CO 12 VDC. 2mA Agencies UL recognized (US & Canada)
