FEATURES

DESCRIPTIONS

Brand ubiquity Model U6-PRO Hardware Features - Management interface: Ethernet and Bluetooth - Network interface: (1) GbE RJ45 port - Buttons: factory reset - LED: White/blue - Power method: PoE+ - Supported voltage range 44-57V DC - Power: UniFi PoE switch -Max. Potency of transmission 2.4GHz / 22dBm 5GHz / 26dBm - MIME 2.4GHz / 2x2 (UL MU-MIMO) 5GHz / 4x4 (DL/UL MU-MIMO) - Yield rate 2.4GHz / 573.5Mbps 5GHz / 4.8Gbps - Antenna gain 2.4GHz / 4dBi 5GHz / 6dBi Wireless Features - 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps - 802.11b: 1, 2, 5.5, 11 Mbps - 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps - 802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) - 802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) - 802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) Software Features - Standards: Wi-Fi 802.11a/b/g Wi-Fi 4 / Wi-Fi 5 / Wi-Fi 6 - Wireless security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) - BSSID: 8 per radio -VLAN: 802.1Q - Advanced QoS: Rate limiting per user - Guest traffic - Simultaneous customers: 300+ - DFS zero wait (Compatible with the next versions of Rmware) Other features Feeding - Supported voltage range: 44-57V DC - Maximum power consumption: 13W Environment - Operating temperature -30 to 60o C (-22 to 140o F) - Operating humidity 5 to 95% non-condensing Dimensions and weight - Dimensions: Ø197 x 35mm (Ø7.76 x 1.38") - Weight without stand: 460 g (1.01 lb) - With stand: 600 g (1.32 lb)
