Poynting Puck 5-in-1 Transportation, IOT, M2M Antenna - Black - SMA - Thread Mount

Product ID:

63855

Identifier:

B09J1G94MD

Brand:

POYNTING ANTENNAS (PTY) LTD.

Model:

Poynting Part # A-PUCK-0005-V1-B

Shipping Weight:

11.97 lbs

Manufacturer:

POYNTING ANTENNAS (PTY) LTD.

Shipping Dimension:

0 x 0 x 0 inches

Share on Social Media

Share on Facebook

Share on X

Share on Instagram

Share on Tiktok

Price of this item is not available.

FEATURES

698 - 3800 MHz; 2X2 LTE (MIMO), 6 dBi; 2X2 Wi-Fi (MIMO), 7.5 dBi; GPS/GLONASS, 21 dBi

Poynting Part # A-PUCK-0005-V1-B is 5G Ready; includes 3.2GHz to 3.8GHz CBRS Band

Gain (max) Port 1 & 2: -1dBi @ 698-960 MHz, 6dBi @ 1710-2700 MHz, 6dBi @ 3200-3800 MHz / Wi-Fi: 5dBi @ 2400-2500 MHz and 7.5dBi @ 5000–6000 MHz

The antenna provides two separate dual-band Wi-Fi antennas offering concurrent 2.4GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax with 2x2 MIMO

Coax Cable Type RTK-031, Cable Length: 2m (6.5ft), Connectors: SMA (male)

Robust, vandal resistant and design provides ruggedness, corrosion, water, dust resistance (IP68)

Ideal for Smart Utilities, digital signage, transportation, marine and IoT/M2M use

Poynting Part # A-PUCK-0005-V1-B

DESCRIPTIONS

Poynting’s new PUCK antenna offers a small profile antenna for use in the IoT/M2M, Smart Meter, Smart Utilities, Transportation, Marine and the Agricultural/Farming markets. The PUCK-5 consists of a 5-in-1 antenna system within a single housing, featuring 2X2 MIMO LTE, 2X2 MIMO Wi-Fi (Dual-band 2.4 GHz & 5 GHz) and GPS/GLONASS. The 2x Cellular MIMO antennas (for 2G/3G/4G) cover the 698 MHz to 3800 MHz band, this includes the most popular international LTE bands. The antenna provides two separate dual-band Wi-Fi antennas offering concurrent 2.4GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax with 2x2 MIMO. The fifth antenna is a high-performance active GPS/GLONASS system operating at temperatures as low as -40ºC. The PUCK-5 is suitable for the following Cellular frequency bands 698-960 MHz, 1710-3800 MHz and the following Wi-Fi frequency bands 2400-2500 MHz and 5000-6000 MHz. Poynting Part # A-PUCK-0005-V1-B
